HC-06 Bluetooth Serial Wireless 4 PinS Bluetooth RF Transceiver Module

Product Categories

Oky Newstar Technology Co., Ltd

Contact Now

HC-06 Bluetooth Serial Wireless 4 PinS Bluetooth RF Transceiver Module

Brand Name : OEM

Model Number : oky3373

Place of Origin : China

MOQ : 10pieces

Price : $1.9-$2.5/piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal

Supply Ability : 1000pcs per week

Delivery Time : 3-5 working days

Packaging Details : Different package at optional: 1. Retailing Package:Anti-static bag 2. Bulking Packing:20Pcs/Lot 3. Retailing Box package design according to your requirement( Order > 3000PCS)

USB protocol : USB protocol

Frequency : 2.4GHz ISM band

Power Supply : +3.3VDC 50mA

Working temperatur : –5 ~ +45 Centigrade

Synchronous : 1Mbps/1Mbps

Support profile : Bluetooth serial port

Size : 43mm x 15mm

Weight : 5g

Modulation : GFSK

Rate: Asynchronous : 2.1Mbps(Max) /160 kbps

Contact Now

HC-06 Wireless Bluetooth Module Slave Wireless Serial Port

Description:

USB protocol	USB v1.1/2.0
Frequency:	2.4GHz ISM band
Modulation:	GFSK
Transmit power	’=4dBm, Class 2
Sensitivity	‘=-84dBm at 0.1% BER
Rate: Asynchronous	2.1Mbps(Max) /160 kbps
Synchronous	1Mbps/1Mbps
Support profile	Bluetooth serial port
Power Supply	+3.3VDC 50mA
Working temperatur	–5 ~ +45 Centigrade
Size:	43mm x 15mm
Weight	5g

Specifications:

Size: Approx. 43mm x 15mm
Input voltage: 3.6-6V
Working current: matching for 30 mA, matching the communication for 10 mA
Output Power Class: Class 2

Competitive Advantages:

1. Convenient & Friendly Customer Service.

2. Low Prices Direct From Factory Suppliers.
3. Fast Delivery Around the World.
4. High Quality With Global Standards.
5. 1 Year Factory Warranty.
6. Safe Shipping Way and Payment

FAQ:

1. What is the delivery time?

Normally, 1-5 workdays after payment;

Special requirement orders, delivery time is negotiable.

2.If the products can’t work after receiving it,what should I do?

We will replace new items for you at once, and respect your final decision for wrong goods.

3.If the products don’t meet my demand after I received it,can I return it?

Yes,no problem.

You can return back to us, we will refund your full payment.

PHOTOS:

HC-06 Bluetooth Serial Wireless 4 PinS Bluetooth RF Transceiver Module
